SR22 G5
On 17 January 2013, Cirrus Aircraft announced the fourth generation of the SR22 (skipping G4 as a designation for the new version of the aircraft). Features included a 200 lb (91 kg) increase in the maximum takeoff weight, and some previous options—60/40 split back seat, ADS-B transponder, and Garmin GFC700 autopilot—became standard equipment. The wheel pants were redesigned and included an access door for the inflator valve. Cirrus improved the aircraft's ballistic parachute using a larger canopy to account for the higher takeoff weight, and a more powerful rocket. The rocket firing changed to a fail-safe electronic ignition, with a maximum operating speed of 140 knots (up from 133 knots). Earlier versions used a pyrotechnic rocket ignition system. Maximum flap speeds were increased to 150 knots (first notch); 110 knots (second notch); and added another 3.5 degrees of extension. Fuel burn slightly increased at cruise speeds, rate of climb was reduced, liftoff speed increased to 80 knots (from 72 knots), and stall speed increased to 60 knots (from 58 knots).
Type your paragraph here.
Model SR22
Serial Number: 4013
Registration Number:N347MW
Delivered Weight Data
& Equipment List
21 Air Conditioning
21-02 Compressor O 1 21119-006 15.0 93.1
21-03 Condenser Assembly O 1 21209-002 17.0 132.8
21-04 Evaporator Assembly O 1 21114-006 17.5 199.5
22 AutoFlight
22-02 Garmin Autopilot Controller S 1 24645-xxx 0.8 126.5
22-03 Altitude Transducer S 1 12722-002 0.2 112.4
25 Equipment & Furnishings
25-02 Emergency Locator Transmitter & Batteries (406 MHz) C 1 17190-101 3.4 229.5
25-03 Fwd Seat & Restraint Inst. (Leather: add 0.4 lb each) C 2 29491-0xx 27.0 149.3
25-05 Rear bench seat Installation (Leather: add 0.8 lb) C 1 29429, 29428, 29427 26.9 183.0
25-07 Rear Seat Restraint 3 point - 3 seat belt C 1 29405-002 5.1 200.0
26 Fire Protection
26-01 Portable Fire Extinguisher C 1 12533-003 1.5 118.4
27 Flight Controls
27-01 Flap Actuator, Modified C 1 11787-002 4.4 173.9
27-02 Roll Trim Cartridge Assy C 1 15660-001 0.4 161.8
27-03 Roll Trim Motor Assembly C 1 12546-003 1.3 159.8
27-06 Pitch Trim Cartridge Assy C 1 15560-002 0.4 310.9
27-07 Pitch Trim Motor Assy C 1 11794-004 1.3 303.5
27-08 Yaw Trim Cartridge Assy C 1 11898-002 0.4 106.2
33 Lights
33-01 L/R Strobe/Nav Lights C 2 17140-005/-006 0.6 161.8
33-02 Strobe Power Supply (2) C 2 14286-002 1.7 147.8
33-03 Landing Light Installation S 1 18983-005 1.9 80.0
33-04 Recognition Light Installation S 2 18957-003/-004 0.4 138.5
34 Navigation & Pitot Static
23-02 Com 1 Antenna C 1 12740-004 0.5 178.5
23-03 Com 2 Antenna S 1 12741-002 0.5 204.6
34-02 Garmin 12" Display O 1 24655-003 9.3 118.5
34-03 Garmin 12" Display C 1 24655-004 9.3 117.0
34-07 Altimeter C 1 12102-002 1.1 116.1
34-08 Airspeed Indicator C 1 13562-xxx 0.7 116.9
34-09 Magnetic Compass C 1 12451-002 0.3 132.7
34-10 Attitude Gyro C 1 24668-001 2.2 114.5
34-11 Marker Beacon Antenna S 1 12743-003 0.6 200.0
34-12 GPS 1 Antenna C 1 12744-004 0.4 136.2
34-13 GPS 2 Antenna/Iridium Combo Antenna S 1 29301-001 0.4 200.0
34-14 Transponder Antenna C 1 12739-001 0.1 105.0
34-15 VOR/LOC Antenna C 1 12742-001 0.4 331.0
34-16 Turn Coordinator, Modified C 0 11891-001 1.8 118.0
34-18 GMA 350 Audio Panel O 1 29396-001 1.6 125.8
34-22 GPS/NAV/COM#1 GIA63W O 1 24662-002 6.3 110.5
34-23 GPS/NAV/COM#2 GIA63W O 1 24662-002 6.3 111.0
34-24 AIR DATA COMPUTER, GDC 74 O 2 24651-001 2.0 112.5
34-25 AHRS UNIT, GRS 77 O 2 24661-003 3.3 110.0
34-26 CO Detector O 1 24660-xxx 0.2 104.0
34-27 FMS Keyboard, GCU 478 O 1 24654-002 1.0 124.0
Engine Monitoring
34-33 Rack/Unit Installation, GEA 71 O 1 24661-001 2.2 111.5
Traffic Option
34-42 Garmin Traffic GTS 800 O 1 26659-001 9.9 139.0
34-43 Antenna, Monopole O 1 26656-001 0.2 157.2
34-44 Antenna, Directional, GA 58 O 1 26659-050 0.8 180.0
Transponder Option
34-53 Mode S w/ES Transponder O 1 24653-002 2.6 230.0
XM Satellite Options
34-55 XM WX/Radio Receiver (Perspective) O 1 24657-001/-002 2.7 228.0
34-56 XM Radio Remote Control O 1 24641-001 0.2 149.3
35 Oxygen
35-01 Bottle Assembly - Empty O 1 100N0020-4 19.9 262.3
35-02 Full 23.8 265.3
61 Propeller
61-01 Hartzell Propeller Installation C 1 15319-00X 79.8 48.0
61-06 Propeller Governor C 1 15524-001 3.2 61.7
72 Engine
72-03 Induction Filter C 1 50207-200 0.4 62.9
72-04 Tanis Engine Pre-heater O 1 25028-001 2.1 61.0
95 Special Equipment
95-03 Enhanced Vision System O 1 24737-007 1.2 161.0
Sym:
Items in this listing are coded by a symbol indicating the status of the item. These codes are: C Required item for FAA Certification. S Standard equipment. Most standard equipment is applicable to all airplanes. Some equipment may be replaced by optional equipment. O Optional equipment. Optional equipment may be installed in addition to or to replace standard equipment. Qty: The quantity of the listed item in the airplane. A hyphen (-) in this column indicates that the equipment was not installed
Part Number
This is the Cirrus Design Part Number for the component, assembly, or installation Unit Wt The weight, in pounds, of one each of the listed item.
Arm
The arm, in inches, of the listed item
Located in St. Petersburg FL (KSPG)
2013 SR-22 GTS
Specifications:
AIRFRAME 788
Engine 788 SNEW
Prop 788 SNEW
Avionics/Radios
All Specifications Subject to Verification Upon Inspection
Availability Subject to Sale, or Withdrawal From Market Without Notice
BEAUTIFUL HOMES
Click picture of book to see Logs
2013 SR22 GTS. GARMIN CIRRUS PERSPECTIVE , FIKI, Fresh Annual and CAPS Repack prepaid ,GPS WASS , always hangered , NO Damage History, complete logs. Electronic Approach Charts, XM Weather and Terrain Awareness. Call or email today!
